1. The controller performs 2 transfers. If the number of transfers remaining is zero the flow continues
1. The controller performs 2 transfers for channel C. If the number of transfers remaining is zero the
...the world's most energy friendly microcontrollers
DMA transfer completes. Therefore, you must take care when setting the R_power, that you do not
significantly increase the latency for high-priority channels.
8.4.2.3.1 Invalid
After the controller completes a DMA cycle it sets the cycle type to invalid, to prevent it from repeating
the same DMA cycle.
8.4.2.3.2 Basic
In this mode, you configure the controller to use either the primary, or alternate, data structure. After you
enable the channel, and the controller receives a request then the flow for this DMA cycle is:
R
2. The controller arbitrates:
? if a higher-priority channel is requesting service then the controller services that channel
? if the peripheral or software signals a request to the controller then it continues at step 1 (p. 55) .
3. The controller sets dma_done[C] HIGH for one HFCORECLK cycle. This indicates to the host
processor that the DMA cycle is complete.
8.4.2.3.3 Auto-request
When the controller operates in this mode, it is only necessary for it to receive a single request to enable
it to complete the entire DMA cycle. This enables a large data transfer to occur, without significantly
increasing the latency for servicing higher priority requests, or requiring multiple requests from the
processor or peripheral.
You can configure the controller to use the primary, or alternate, data structure. After you enable the
channel, and the controller receives a request for this channel, then the flow for this DMA cycle is:
R
2. The controller arbitrates. When channel C has the highest priority then the DMA cycle continues at
3. The controller sets dma_done[C] HIGH for one HFCORECLK cycle. This indicates to the host
processor that the DMA cycle is complete.
8.4.2.3.4 Ping-pong
In ping-pong mode, the controller performs a DMA cycle using one of the data structures and it then
performs a DMA cycle using the other data structure. The controller continues to switch from primary to
alternate to primary… until it reads a data structure that is invalid, or until the host processor disables
the channel.
2012-04-24 - Giant Gecko Family - d0053_Rev0.96
55
www.energymicro.com
